11. Safety devices
Type of
protection
Protection form
Model
AOYG09KBTB AOYG12KBTB AOYG14KBTB
Circuit
protection
Current fuse (Main PCB)
250 V, 20 A 250 V, 25 A
250 V, 5 A
250 V, 3.15 A
Fan motor
protection
Terminal protection
program
Activate
125 ±25 °C
Fan motor stop
100 ±15 °C
Fan motor stop
Reset
100 ±25 °C
Fan motor restart
95 ±10 °C
Fan motor restart
Compressor
protection
Terminal protection
program
(Discharge temp.)
Activate
110 °C
Compressor stop
Reset
After 7 minutes
Compressor restart
Thermal protection
program (Outdoor temp.)
(Only in COOL or DRY
mode)
Activate
-20 °C
Compressor stop
Reset
-15 °C
Compressor restart
Type of
protection
Protection form
Model
AOYG18KBTB AOYG22KBTB
Circuit
protection
Current fuse (Main PCB)
250 V, 25 A
250 V, 5 A
250 V, 3.15 A
Fan motor
protection
Terminal protection
program
Activate
125±10 °C
Fan motor stop
Reset
120±10 °C
Fan motor restart
Compressor
protection
Terminal protection
program
(Discharge temp.)
Activate
110 °C
Compressor stop
Reset
After 7 minutes
Compressor restart
Terminal protection
program
(Compressor temp.)
Activate —
108 °C
Compressor stop
Reset —
After 3 minutes, and 80 °C or less
Compressor restart
Thermal protection
program (Outdoor temp.)
(Only in COOL or DRY
mode)
Activate
-20 °C
Compressor stop
Reset
-15 °C
Compressor restart
High
pressure
protection
Pressure switch
Activate —
4.2
+0
-0.15
MPa
Compressor stop
Reset —
3.2 ±0.15 MPa
Compressor restart
