Evaporator Total Assy
9316893078
52
Joint Pipe Assy
9317190015
53
Filter Guide
9316578005
55
54
Evaporator Holder R
9316565005
56
Evaporator Holder L
9316564008
Rear Bracket
9316566019
57
Room Thermistor Holder
9316895003
Ref.
Description
Part number
INDOOR UNIT
Evaporator
2011.01.25
51
16
18
Table of Contents
Contents
1
Room Air Conditioner
1
Wall Mounted Type
1
Indoor Unit
1
Outdoor Unit
1
Specifications
2
Electrical Data
2
Fan Motor
2
Noise Level
2
Dimensions
3
Indoor Unit
3
Outdoor Unit
3
Refrigerant System Diagram
4
Refrigerant Direction
4
Refrigerant Pipe Diameter
4
Circuit Diagram
5
Indoor PCB Circuit Diagram
6
Indicator Pcb Assembly
8
Indoor Unit Remote Control
12
Error Detection
12
Indoor Unit Display
12
Error Code
12
Parts
14
Front Panel
14
Casing Assy
15
Control Box
16
Evaporator
17
Accessories
21
Option
21
