14
2011.01.25
INDOOR UNIT
21
22
Joint Pipe Assy
Evaporator Total Assy
23
Holder (Room Thermistor)
Thermistor Assy
24
25
Evaporator Holder R
26
Filter Guide
Parts number
Description
Ref
9317820028
9317838016
9317652001
9317651004
9317650007
9317649001
Rear Bracket
27
28
Evaporator Holder L
9316895003
9900563004
21
27
28
22
23
24
26
25
14
16
Table of Contents
Table of Contents
1
Wall Mounted Type
1
Indoor Unit
1
Specifications
2
Dimensions
3
Refrigerant System Diagram
4
Circuit Diagram
5
Indoor Pcb Circuit Diagram
6
R202 C203
8
Outdoor Pcb Circuit Diagram
10
Indoor Unit Remote Control
12
Error Detection
12
Parts (Indoor Unit)
14
Parts (Outdoor Unit)
18
Accessories
21
