DIMENSIONS
unit : mm
2011.03.09 2
INDOOR UNIT
OUTDOOR UNIT
Drain pipe diameter
16.2 mm
Liquid pipe diameter : 6.35 mm
Gas pipe diameter : 12.7 mm
540
290790
540
205 : Installed state
*1: Vertical flap is downward
203
140 *1
10 *1
145 *1
790
280
