13
2011.01.25
PARTS
INDOOR UNIT
1
2
Front Panel
Front Panel Total Assy
3
Wire Cover
Wire Shield
4
5
Air Filter
6
Intake Grille Assy
Parts number
Description
Ref
9318267099
9317642057
9332458008
9316906006
9317644013
9317643016
7
Clamper Grille
8
9
Receiver Window
Panel Cover
Air Clean Filter Assy
9317646017
9317663007
9317664011
9318912005
9317250009
10
Bracket Panel
Remote Control
9317665001
11
12
--
Remote Control Holder
9319208008
1
4
5
3
2
4
1
1
12
10
6
7
9
8
13
15
Table of Contents
Table of Contents
1
Wall Mounted Type
1
Indoor Unit
1
Specifications
2
Dimensions
3
Refrigerant System Diagram
4
Circuit Diagram
5
Indoor Pcb Circuit Diagram
6
R202 C203
8
Outdoor Pcb Circuit Diagram
10
Indoor Unit Remote Control
12
Error Detection
12
Parts (Indoor Unit)
14
Parts (Outdoor Unit)
18
Accessories
21
