Fujitsu AOYG18KBTA2 User Manual

Models: ASYG07KETA, ASYG07KETA-B, ASYG07KETE, ASYG07KETE-B, ASYG07KETF, and
ASYG07KETF-B
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 1.80 1.01 2.04 1.16 2.15 1.33 2.30 1.50 2.46 1.64 2.53 1.87
0.0 1.80 1.01 2.04 1.16 2.15 1.33 2.30 1.50 2.46 1.64 2.53 1.87
5.0 1.80 1.01 2.04 1.16 2.15 1.33 2.30 1.50 2.46 1.64 2.53 1.87
10.0 1.80 1.01 2.04 1.16 2.15 1.33 2.30 1.50 2.46 1.64 2.53 1.87
15.0 1.80 1.01 2.04 1.16 2.15 1.33 2.30 1.50 2.46 1.64 2.53 1.87
20.0 1.80 1.01 2.04 1.16 2.15 1.33 2.30 1.50 2.46 1.64 2.53 1.87
25.0 1.80 1.01 2.04 1.16 2.15 1.33 2.30 1.50 2.46 1.64 2.53 1.87
30.0 1.80 1.01 2.04 1.16 2.15 1.33 2.30 1.50 2.46 1.64 2.53 1.87
35.0 1.80 1.01 2.04 1.16 2.15 1.33 2.30 1.50 2.46 1.64 2.53 1.87
40.0 1.57 0.76 1.77 0.87 1.87 1.00 2.00 1.13 2.13 1.23 2.20 1.41
46.0 1.36 0.58 1.54 0.66 1.62 0.76 1.74 0.85 1.86 0.93 1.91 1.07
Models: ASYG09KETA, ASYG09KETA-B, ASYG09KETE, ASYG09KETE-B, ASYG09KETF, and
ASYG09KETF-B
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.03 1.14 2.29 1.30 2.42 1.50 2.59 1.68 2.77 1.84 2.85 2.11
0.0 2.03 1.14 2.29 1.30 2.42 1.50 2.59 1.68 2.77 1.84 2.85 2.11
5.0 2.03 1.14 2.29 1.30 2.42 1.50 2.59 1.68 2.77 1.84 2.85 2.11
10.0 2.03 1.14 2.29 1.30 2.42 1.50 2.59 1.68 2.77 1.84 2.85 2.11
15.0 2.03 1.14 2.29 1.30 2.42 1.50 2.59 1.68 2.77 1.84 2.85 2.11
20.0 2.03 1.14 2.29 1.30 2.42 1.50 2.59 1.68 2.77 1.84 2.85 2.11
25.0 2.03 1.14 2.29 1.30 2.42 1.50 2.59 1.68 2.77 1.84 2.85 2.11
30.0 2.03 1.14 2.29 1.30 2.42 1.50 2.59 1.68 2.77 1.84 2.85 2.11
35.0 2.03 1.14 2.29 1.30 2.42 1.50 2.59 1.68 2.77 1.84 2.85 2.11
40.0 1.76 0.86 1.99 0.98 2.10 1.13 2.25 1.27 2.40 1.39 2.48 1.59
46.0 1.53 0.65 1.73 0.74 1.83 0.85 1.96 0.96 2.09 1.05 2.16 1.20
Models: ASYG12KETA, ASYG12KETA-B, ASYG12KETE, ASYG12KETE-B, ASYG12KETF, and
ASYG12KETF-B
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.28 1.28 2.58 1.46 2.72 1.68 2.91 1.89 3.11 2.07 3.21 2.37
0.0 2.28 1.28 2.58 1.46 2.72 1.68 2.91 1.89 3.11 2.07 3.21 2.37
5.0 2.28 1.28 2.58 1.46 2.72 1.68 2.91 1.89 3.11 2.07 3.21 2.37
10.0 2.28 1.28 2.58 1.46 2.72 1.68 2.91 1.89 3.11 2.07 3.21 2.37
15.0 2.28 1.28 2.58 1.46 2.72 1.68 2.91 1.89 3.11 2.07 3.21 2.37
20.0 2.28 1.28 2.58 1.46 2.72 1.68 2.91 1.89 3.11 2.07 3.21 2.37
25.0 2.28 1.28 2.58 1.46 2.72 1.68 2.91 1.89 3.11 2.07 3.21 2.37
30.0 2.28 1.28 2.58 1.46 2.72 1.68 2.91 1.89 3.11 2.07 3.21 2.37
35.0 2.28 1.28 2.58 1.46 2.72 1.68 2.91 1.89 3.11 2.07 3.21 2.37
40.0 1.98 0.97 2.24 1.10 2.36 1.27 2.53 1.43 2.70 1.56 2.78 1.79
46.0 1.72 0.73 1.95 0.83 2.05 0.96 2.20 1.08 2.35 1.18 2.42 1.35
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
- 307 -
6-2. Cooling capacity 6. Capacity table
OUTDOOR UNIT AOYG14-18KBTA2 OUTDOOR UNIT AOYG14-18KBTA2

Fujitsu AOYG18KBTA2 Specifications

General

Brand	Fujitsu
Model	AOYG18KBTA2
Category	Air Conditioner
Language	English
