Fujitsu AOYG18KBTA2 User Manual

¢
Model: AOYG18KBTA2
Indoor unit connecting
capacity
Outdoor temperature
Indoor temperature
16.0 °CDB 18.0 °CDB 20.0 °CDB 22.0 °CDB 24.0 °CDB
kBtu/h °CDB °CWB TC IP TC IP TC IP TC IP TC IP
26
-15.0
-16.0 4.0 1.63 3.9 1.67 3.8 1.70 3.7 1.73 3.6 1.77
-10.0 -11.0 4.6 1.68 4.4 1.72 4.3 1.75 4.2 1.79 4.1 1.82
-5.0 -7.0 5.2 1.73 5.0 1.76 4.9 1.80 4.8 1.84 4.7 1.87
0.0 -2.0 6.6 1.90 6.4 1.94 6.3 1.98 6.1 2.02 5.9 2.06
5.0 3.0 7.4 1.90 7.2 1.94 7.0 1.98 6.8 2.02 6.7 2.06
7.0 6.0 7.4 1.80 7.2 1.84 7.0 1.88 6.8 1.92 6.7 1.96
10.0 8.0 7.4 1.69 7.2 1.73 7.0 1.77 6.8 1.80 6.7 1.84
15.0 10.0 7.4 1.55 7.2 1.59 7.0 1.62 6.8 1.65 6.7 1.68
20.0 15.0 7.4 1.31 7.2 1.34 7.0 1.37 6.8 1.40 6.7 1.42
24.0 18.0 7.4 1.15 7.2 1.18 7.0 1.20 6.8 1.23 6.7 1.25
24
-15.0
-16.0 4.0 1.63 3.9 1.67 3.8 1.70 3.7 1.73 3.6 1.77
-10.0 -11.0 4.6 1.68 4.4 1.72 4.3 1.75 4.2 1.79 4.1 1.82
-5.0 -7.0 5.2 1.73 5.0 1.76 4.9 1.80 4.8 1.84 4.7 1.87
0.0 -2.0 6.6 1.90 6.4 1.94 6.3 1.98 6.1 2.02 5.9 2.06
5.0 3.0 7.4 1.90 7.2 1.94 7.0 1.98 6.8 2.02 6.7 2.06
7.0 6.0 7.4 1.80 7.2 1.84 7.0 1.88 6.8 1.92 6.7 1.96
10.0 8.0 7.4 1.69 7.2 1.73 7.0 1.77 6.8 1.80 6.7 1.84
15.0 10.0 7.4 1.55 7.2 1.59 7.0 1.62 6.8 1.65 6.7 1.68
20.0 15.0 7.4 1.31 7.2 1.34 7.0 1.37 6.8 1.40 6.7 1.42
24.0 18.0 7.4 1.15 7.2 1.18 7.0 1.20 6.8 1.23 6.7 1.25
23
-15.0
-16.0 4.0 1.63 3.9 1.67 3.8 1.70 3.7 1.73 3.6 1.77
-10.0 -11.0 4.6 1.68 4.4 1.72 4.3 1.75 4.2 1.79 4.1 1.82
-5.0 -7.0 5.2 1.73 5.0 1.76 4.9 1.80 4.8 1.84 4.7 1.87
0.0 -2.0 6.6 1.90 6.4 1.94 6.3 1.98 6.1 2.02 5.9 2.06
5.0 3.0 7.4 1.90 7.2 1.94 7.0 1.98 6.8 2.02 6.7 2.06
7.0 6.0 7.4 1.80 7.2 1.84 7.0 1.88 6.8 1.92 6.7 1.96
10.0 8.0 7.4 1.69 7.2 1.73 7.0 1.77 6.8 1.80 6.7 1.84
15.0 10.0 7.4 1.55 7.2 1.59 7.0 1.62 6.8 1.65 6.7 1.68
20.0 15.0 7.4 1.31 7.2 1.34 7.0 1.37 6.8 1.40 6.7 1.42
24.0 18.0 7.4 1.15 7.2 1.18 7.0 1.20 6.8 1.23 6.7 1.25
21
-15.0
-16.0 4.0 1.63 3.9 1.67 3.8 1.70 3.7 1.73 3.6 1.77
-10.0 -11.0 4.6 1.68 4.4 1.72 4.3 1.75 4.2 1.79 4.1 1.82
-5.0 -7.0 5.2 1.73 5.0 1.76 4.9 1.80 4.8 1.84 4.7 1.87
0.0 -2.0 6.6 1.90 6.4 1.94 6.3 1.98 6.1 2.02 5.9 2.06
5.0 3.0 7.4 1.90 7.2 1.94 7.0 1.98 6.8 2.02 6.7 2.06
7.0 6.0 7.4 1.80 7.2 1.84 7.0 1.88 6.8 1.92 6.7 1.96
10.0 8.0 7.4 1.69 7.2 1.73 7.0 1.77 6.8 1.80 6.7 1.84
15.0 10.0 7.4 1.55 7.2 1.59 7.0 1.62 6.8 1.65 6.7 1.68
20.0 15.0 7.4 1.31 7.2 1.34 7.0 1.37 6.8 1.40 6.7 1.42
24.0 18.0 7.4 1.15 7.2 1.18 7.0 1.20 6.8 1.23 6.7 1.25
19
-15.0
-16.0 4.0 1.63 3.9 1.67 3.8 1.70 3.7 1.73 3.6 1.77
-10.0 -11.0 4.6 1.68 4.4 1.72 4.3 1.75 4.2 1.79 4.1 1.82
-5.0 -7.0 5.2 1.73 5.0 1.76 4.9 1.80 4.8 1.84 4.7 1.87
0.0 -2.0 6.6 1.90 6.4 1.94 6.3 1.98 6.1 2.02 5.9 2.06
5.0 3.0 7.4 1.90 7.2 1.94 7.0 1.98 6.8 2.02 6.7 2.06
7.0 6.0 7.4 1.80 7.2 1.84 7.0 1.88 6.8 1.92 6.7 1.96
10.0 8.0 7.4 1.69 7.2 1.73 7.0 1.77 6.8 1.80 6.7 1.84
15.0 10.0 7.4 1.55 7.2 1.59 7.0 1.62 6.8 1.65 6.7 1.68
20.0 15.0 7.4 1.31 7.2 1.34 7.0 1.37 6.8 1.40 6.7 1.42
24.0 18.0 7.4 1.15 7.2 1.18 7.0 1.20 6.8 1.23 6.7 1.25
18
-15.0
-16.0 4.0 1.63 3.9 1.66 3.8 1.69 3.7 1.73 3.6 1.76
-10.0 -11.0 4.6 1.67 4.4 1.71 4.3 1.74 4.2 1.78 4.1 1.81
-5.0 -7.0 5.2 1.72 5.0 1.76 4.9 1.79 4.8 1.83 4.7 1.87
0.0 -2.0 6.6 1.90 6.4 1.94 6.3 1.98 6.1 2.02 5.9 2.06
5.0 3.0 7.4 1.90 7.2 1.94 7.0 1.98 6.8 2.02 6.7 2.06
7.0 6.0 7.4 1.80 7.2 1.84 7.0 1.88 6.8 1.92 6.7 1.96
10.0 8.0 7.4 1.69 7.2 1.73 7.0 1.77 6.8 1.80 6.7 1.84
15.0 10.0 7.4 1.55 7.2 1.59 7.0 1.62 6.8 1.65 6.7 1.68
20.0 15.0 7.4 1.31 7.2 1.34 7.0 1.37 6.8 1.40 6.7 1.42
24.0 18.0 7.4 1.15 7.2 1.18 7.0 1.20 6.8 1.23 6.7 1.25
16
-15.0
-16.0 3.6 1.46 3.5 1.49 3.4 1.52 3.4 1.55 3.3 1.58
-10.0 -11.0 4.2 1.50 4.1 1.53 4.0 1.56 3.9 1.59 3.8 1.62
-5.0 -7.0 4.7 1.55 4.6 1.58 4.5 1.61 4.4 1.64 4.3 1.67
0.0 -2.0 6.0 1.70 5.9 1.73 5.7 1.77 5.6 1.81 5.4 1.84
5.0 3.0 6.7 1.70 6.6 1.73 6.4 1.77 6.2 1.81 6.1 1.84
7.0 6.0 6.7 1.61 6.6 1.65 6.4 1.68 6.2 1.71 6.1 1.75
10.0 8.0 6.7 1.51 6.6 1.55 6.4 1.58 6.2 1.61 6.1 1.64
15.0 10.0 6.7 1.39 6.6 1.42 6.4 1.45 6.2 1.48 6.1 1.50
20.0 15.0 6.7 1.17 6.6 1.20 6.4 1.22 6.2 1.25 6.1 1.27
24.0 18.0 6.7 1.03 6.6 1.05 6.4 1.07 6.2 1.09 6.1 1.12
14
-15.0
-16.0 3.2 1.22 3.1 1.24 3.0 1.27 2.9 1.30 2.9 1.32
-10.0 -11.0 3.6 1.26 3.6 1.28 3.5 1.31 3.4 1.34 3.3 1.36
-5.0 -7.0 4.1 1.30 4.0 1.32 3.9 1.35 3.8 1.38 3.7 1.40
0.0 -2.0 5.3 1.43 5.1 1.46 5.0 1.49 4.9 1.52 4.8 1.55
5.0 3.0 5.9 1.43 5.7 1.46 5.6 1.49 5.5 1.52 5.3 1.55
7.0 6.0 5.9 1.35 5.7 1.38 5.6 1.41 5.5 1.44 5.3 1.47
10.0 8.0 5.9 1.27 5.7 1.30 5.6 1.32 5.5 1.35 5.3 1.38
15.0 10.0 5.9 1.17 5.7 1.19 5.6 1.21 5.5 1.24 5.3 1.26
20.0 15.0 5.9 0.99 5.7 1.01 5.6 1.03 5.5 1.05 5.3 1.07
24.0 18.0 5.9 0.86 5.7 0.88 5.6 0.90 5.5 0.92 5.3 0.94
- 326 -
6-3. Heating capacity 6. Capacity table
OUTDOOR UNIT AOYG14-18KBTA2 OUTDOOR UNIT AOYG14-18KBTA2

Fujitsu AOYG18KBTA2 Specifications
