Fujitsu AOYG24KLTA User Manual

4. Capacity table
Capacity tables show each of following values calculated based on the outdoor temperature and
the indoor temperature, under given Airflow Rate (AFR):
For cooling capacity: Total Capacity (TC), Sensible Heat Capacity (SHC), and Input Power (IP)
For heating capacity: Total Capacity (TC) and Input Power (IP)
4-1. Cooling capacity
¢
M
odel: ASYG18KLCA
AFR
m
3
/h
865
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-10 3.20 2.79 1.99 3.51 3.05 2.01 3.61 3.15 2.03 3.84 3.35 2.05 3.96 3.45 2.07 4.22 3.68 2.09 4.50 3.92 2.11
-5 2.94 2.69 1.99 3.22 2.94 2.01 3.31 3.03 2.03 3.52 3.22 2.05 3.63 3.32 2.07 3.87 3.54 2.09 4.13 3.77 2.11
0 2.67 2.59 1.99 2.93 2.83 2.01 3.02 2.91 2.03 3.21 3.10 2.05 3.31 3.20 2.07 3.52 3.41 2.09 3.76 3.63 2.11
5 3.49 2.96 1.95 3.82 3.24 1.97 3.93 3.34 1.99 4.18 3.55 2.02 4.31 3.66 2.04 4.60 3.90 2.06 4.90 4.16 2.08
10 3.24 2.85 1.98 3.54 3.11 2.00 3.65 3.21 2.02 3.88 3.41 2.04 4.00 3.52 2.06 4.26 3.75 2.08 4.55 4.00 2.10
15 4.80 3.47 1.19 5.25 3.80 1.20 5.41 3.91 1.22 5.75 4.16 1.23 5.93 4.29 1.24 6.32 4.57 1.25 6.74 4.87 1.26
20 4.61 3.39 1.34 5.05 3.71 1.36 5.20 3.82 1.37 5.53 4.06 1.39 5.70 4.19 1.40 6.08 4.46 1.41 6.48 4.76 1.43
25 4.58 3.36 1.33 5.01 3.68 1.35 5.16 3.79 1.36 5.49 4.03 1.37 5.66 4.16 1.39 6.03 4.43 1.40 6.43 4.72 1.41
30 4.39 3.27 1.47 4.81 3.58 1.49 4.95 3.69 1.51 5.27 3.92 1.52 5.43 4.04 1.54 5.78 4.31 1.55 6.17 4.59 1.57
35 4.21 3.18 1.62 4.60 3.48 1.63 4.74 3.59 1.65 5.04 3.81 1.67 5.20 3.93 1.69 5.54 4.19 1.70 5.91 4.46 1.72
40 3.55 2.98 1.34 3.88 3.26 1.35 4.00 3.36 1.37 4.25 3.57 1.38 4.39 3.68 1.39 4.67 3.92 1.41 4.98 4.18 1.42
46 2.47 2.47 0.98 2.70 2.70 0.99 2.78 2.78 1.00 2.96 2.96 1.01 3.05 3.05 1.02 3.25 3.25 1.03 3.46 3.46 1.04
¢
M
odel: ASYG24KLCA
AFR
m
3
/h
1,040
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-10 6.01 4.00 2.32 6.58 4.38 2.34 6.78 4.51 2.37 7.21 4.80 2.39 7.43 4.94 2.41 7.92 5.27 2.44 8.44 5.62 2.46
-5 5.57 3.82 2.48 6.10 4.18 2.50 6.29 4.30 2.53 6.69 4.58 2.55 6.89 4.72 2.58 7.34 5.03 2.61 7.83 5.36 2.63
0 5.14 3.64 2.64 5.62 3.98 2.66 5.79 4.10 2.69 6.16 4.36 2.72 6.35 4.49 2.75 6.77 4.79 2.77 7.21 5.11 2.80
5 5.96 4.02 2.31 6.53 4.40 2.34 6.73 4.54 2.36 7.15 4.83 2.38 7.37 4.97 2.41 7.86 5.30 2.43 8.38 5.65 2.46
10 5.63 3.95 2.46 6.16 4.32 2.48 6.35 4.45 2.51 6.75 4.73 2.53 6.96 4.88 2.56 7.42 5.20 2.59 7.91 5.54 2.61
15 6.65 4.40 1.61 7.27 4.81 1.62 7.50 4.96 1.64 7.97 5.27 1.66 8.22 5.43 1.67 8.76 5.79 1.69 9.33 6.17 1.71
20 6.45 4.29 1.81 7.06 4.69 1.83 7.28 4.83 1.85 7.74 5.14 1.87 7.98 5.30 1.89 8.50 5.65 1.90 9.06 6.02 1.92
25 6.31 4.23 1.92 6.91 4.62 1.94 7.12 4.76 1.96 7.57 5.07 1.98 7.81 5.22 2.00 8.32 5.57 2.02 8.87 5.93 2.04
30 6.03 4.10 2.12 6.60 4.49 2.14 6.80 4.63 2.17 7.23 4.92 2.19 7.45 5.07 2.21 7.94 5.40 2.23 8.47 5.76 2.25
35 5.74 3.98 2.32 6.28 4.36 2.35 6.48 4.49 2.37 6.89 4.77 2.40 7.10 4.92 2.42 7.57 5.24 2.44 8.07 5.59 2.47
40 5.33 3.85 2.09 5.84 4.21 2.11 6.02 4.34 2.14 6.40 4.61 2.16 6.59 4.75 2.18 7.03 5.07 2.20 7.49 5.40 2.22
46 3.98 3.31 1.59 4.35 3.62 1.61 4.49 3.73 1.63 4.77 3.97 1.64 4.92 4.09 1.66 5.24 4.36 1.68 5.59 4.65 1.69
- 7 -
WALL MOUNTED ASYG18, 24KLCA

Fujitsu AOYG24KLTA Specifications

General

Brand	Fujitsu
Model	AOYG24KLTA
Category	Air Conditioner
Language	English
