4-2. Heating capacity
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
¢
Model: ASYG18KLCA
AFR
m
3
/h
995
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 4.29 1.49 4.18 1.52 4.07 1.55 3.96 1.58 3.85 1.61
-10 -11 4.97 1.60 4.84 1.63 4.71 1.65 4.58 1.70 4.45 1.73
-5 -7 5.74 1.73 5.59 1.77 5.44 1.77 5.29 1.84 5.14 1.87
0 -2 6.67 1.88 6.49 1.92 6.32 1.93 6.14 2.00 5.97 2.04
5 3 7.41 2.01 7.21 2.05 7.02 2.09 6.83 2.13 6.63 2.17
7 6 8.09 2.09 7.88 2.13 7.67 2.18 7.46 2.22 7.25 2.26
10 8 8.47 2.17 8.25 2.21 8.03 2.24 7.81 2.31 7.59 2.35
15 10 8.46 2.00 8.24 2.04 8.02 2.09 7.80 2.12 7.57 2.16
20 15 7.85 1.56 7.64 1.59 7.44 1.63 7.23 1.66 7.03 1.69
24 18 8.24 1.55 8.03 1.59 7.81 1.62 7.59 1.65 7.38 1.68
¢
M
odel: ASYG24KLCA
AFR
m
3
/h
1,040
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 6.90 2.74 6.72 2.79 6.54 2.85 6.36 2.90 6.18 2.96
-10 -11 7.98 3.08 7.77 3.14 7.56 3.14 7.35 3.27 7.14 3.33
-5 -7 8.79 3.25 8.56 3.31 8.33 3.40 8.10 3.45 7.87 3.51
0 -2 9.20 3.16 8.96 3.22 8.72 3.31 8.48 3.35 8.24 3.42
5 3 9.53 2.89 9.28 2.95 9.03 3.01 8.78 3.07 8.53 3.13
7 6 9.50 2.55 9.25 2.60 9.00 2.66 8.75 2.71 8.50 2.76
10 8 9.54 2.45 9.29 2.50 9.04 2.59 8.79 2.60 8.54 2.65
15 10 9.60 2.24 9.35 2.29 9.10 2.38 8.84 2.38 8.59 2.43
20 15 9.66 2.04 9.41 2.08 9.16 2.17 8.90 2.16 8.65 2.20
24 18 9.71 1.87 9.46 1.91 9.20 1.95 8.95 1.99 8.70 2.03
DESIGN & TECHNICAL MANUAL
- 8 -
WALL MOUNTED ASYG18, 24KLCA
