Fujitsu AOYG24LBCA - Refrigerant Circuit; Models: AOYG12 LBLA and AOYG14 LBLA

- 100 -
OUTDOOR UNIT AOYG12-54LB
4. Refrigerant circuit
4-1. Models: AOYG12LBLA and AOYG14LBLA
2-Way
valve
Strainer
Strainer
3-Way
valve
Muffler
4-Way valve
Expansion valve
Heat exchanger
( INDOOR )
Heat exchanger
( OUTDOOR )
C
ompressor
: Cooling
: Heating
Muffler
Sub-accumulator
Th
C
Th
R
Th
D
Th
PI
Th
O
Th
HO
Th
HM
Th
C
: Thermistor (Compressor Temp.)
: Thermistor (Discharge Temp.)
: Thermistor (Outdoor Temp.)
: Thermistor (Heat Exchanger Out Temp.)
Th
D
Th
O
Th
HO
: Thermistor (Heat Exchanger Med Temp.)
Th
HM
: Thermistor (Room Temp.)
: Thermistor (Pipe Temp.)
Th
R
Th
PI
