8-2. Compact cassette type (setting by DIP switch)
By using some components on the PCB, you can change the function settings.
¢ Component location
Components on the indoor unit main PCB used for the function settings are located as shown in
the following figure.
SW100
1 2 3 4
SW101
1 2 3
- 161 -
8-2. Compact cassette type (setting by DIP switch) 8. Function settings
