11. Electrical characteristics
Model name AOYG36KBTB AOYG45KBTB AOYG54KBTB
Power
supply
Voltage V 230 ~
Frequency Hz 50
Max operating current*
1
A 22.6 28.5
Starting current A 13.1 18.6 19.4
Wiring
spec.*
2
Circuit breaker current A 25 32
Power cable
mm
2
4.0
Connection
cable*
3
Cross-sectional
area
mm
2
1.5
Limited wiring
length
m 51
*1: Maximum current is the total current of the indoor unit and the outdoor unit.
*2: Selected sample based on Japan Electrotechnical Standards and Codes Committee E0005. As
the regulations of wire size and circuit breaker differ in each country or region, select appropriate de-
vices complied to the regional standard.
*3: Limit voltage drop to less than 2%. Increase conductor size if voltage drop is 2% or more.
