Fujitsu AOYG45KBTB - Page 74

¢
Heating capacity (Twin)

Compact cassette type
Model: AUXG18KVLA × 2
AFR
m
3
/h
1,600
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 8.05 3.18 8.01 3.18 7.98 3.19 7.77 3.19 7.26 3.20
-10 -11 9.21 3.44 9.17 3.44 9.13 3.44 8.89 3.45 8.31 3.46
-5 -7 10.37 3.69 10.32 3.70 10.28 3.70 10.02 3.71 9.35 3.72
0 -2 11.01 3.74 10.97 3.75 10.92 3.75 10.64 3.75 9.94 3.77
5 3 12.30 3.80 12.24 3.80 12.19 3.81 11.88 3.81 11.09 3.82
7 6 12.81 3.82 12.75 3.83 12.70 3.83 12.37 3.84 11.56 3.85
10 8 13.20 3.82 13.15 3.83 13.09 3.83 12.75 3.84 11.91 3.85
15 10 13.73 3.82 13.68 3.83 13.62 3.83 13.27 3.84 12.39 3.85
20 15 14.63 3.83 14.56 3.84 14.50 3.84 14.13 3.85 13.19 3.86
24 18 15.34 3.84 15.27 3.84 15.21 3.85 14.82 3.85 13.84 3.87

Sl
im duct type
Model: ARXG18KLLAP × 2
AFR
m
3
/h
1,880
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 8.05 3.18 8.01 3.18 7.98 3.19 7.77 3.19 7.26 3.20
-10 -11 9.21 3.44 9.17 3.44 9.13 3.44 8.89 3.45 8.31 3.46
-5 -7 10.37 3.69 10.32 3.70 10.28 3.70 10.02 3.71 9.35 3.72
0 -2 11.01 3.74 10.97 3.75 10.92 3.75 10.64 3.75 9.94 3.77
5 3 12.30 3.80 12.24 3.80 12.19 3.81 11.88 3.81 11.09 3.82
7 6 12.81 3.82 12.75 3.83 12.70 3.83 12.37 3.84 11.56 3.85
10 8 13.20 3.82 13.15 3.83 13.09 3.83 12.75 3.84 11.91 3.85
15 10 13.73 3.82 13.68 3.83 13.62 3.83 13.27 3.84 12.39 3.85
20 15 14.63 3.83 14.56 3.84 14.50 3.84 14.13 3.85 13.19 3.86
24 18 15.34 3.84 15.27 3.84 15.21 3.85 14.82 3.85 13.84 3.87
- 66 -
6-1. Model: AOYG36KBTB 6. Capacity table
OUTDOOR UNIT AOYG36-54KBTB OUTDOOR UNIT AOYG36-54KBTB
