Fujitsu AOYR18LEC User Manual

16
18
24
25
19
13
22
20
15
21
23
2007.10.22 13
INDOOR UNIT
11
17
14
12
Casing Assy 931533103811
12 Casing Cover B 9315016010
13 Casing Cover L 9315017017
14 Casing Cover R 9315018014
15 Casing Cover F 9315019011
20 R and L Louver 9311997016
18 Bush B 9312156016
19 Spacer B 9312441013
16 Drain Cap 9367677009
17 Drain Hose Assy 9315769015
24 Diffuser Z 9315003010
22 Louver Z 9315001016
23 Diffuser U 9315002013
25 Spring C 9314142017
-- Fan Guard Holder R 9315814012
-- Fan Guard 9305751051
-- Fan Guard Holder L 9315815019
21 Louver U 9315000019
Ref
Descriprion Part number

Fujitsu AOYR18LEC Specifications

General

Brand	Fujitsu
Model	AOYR18LEC
Category	Air Conditioner
Language	English
