Fujitsu AOYR18LEC - Page 11

2008.05.16
14
39
32
31
37
41
42
40
35
36
33
34
38
INDOOR UNIT
31 Crossflow Fan Assy 9315024015
32 Bearing C Assy 9306628017
33 Evaporator Assy 9315347015
34 Evaporator Assy B 9315349019
35 Connection Pipe Assy 9315354020
36 Distributor Assy 9316989016
37 Water Seal 9315251015
38
Evaporater Holder R 931499401239
Evaporater Holder L 9314995019
40 Rear Bracket 9315022011
41 Filter Guide 9315013019
42 Filter Guard 9315411013
Ref Descriprion Part number
