2008.04.15 12
PARTS
INDOOR UNIT
3
2
3
5
1
4
4
1
Front Panel Total Assy
9315335012
2 Intake Grille Assy 9315336019
3 Air Filter 9315014016
4 Clamper Grille 9306755010
5 Receiver Window 9315010018
-- Air Clean Filter Assy 9315212016
-- Remote Control 9317445009
--
Remote Control Holder
9305642045
Ref
Descriprion Part number
