Fujitsu ARXG22KMLA Design & Technical Manual

4-2. Heating capacity
NOTE:
Values mentioned in the table are calculated based on the maximum capacity.
¢
Model: ABYG18KRTA
AFR
m
3
/h
840
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 5.05 1.77 4.93 1.81 4.81 1.85 4.69 1.88 4.57 1.92
-10 -11 5.69 1.89 5.56 1.93 5.42 1.96 5.28 2.00 5.15 2.04
-5 -7 6.33 2.00 6.18 2.04 6.03 2.08 5.88 2.12 5.73 2.17
0 -2 6.97 2.12 6.81 2.17 6.64 2.21 6.47 2.25 6.31 2.30
5 3 7.61 2.22 7.43 2.27 7.25 2.32 7.07 2.36 6.89 2.41
7 6 7.88 2.27 7.69 2.31 7.50 2.36 7.31 2.41 7.13 2.45
10 8 8.51 2.36 8.30 2.41 8.10 2.46 7.90 2.51 7.70 2.55
15 10 8.46 2.08 8.26 2.12 8.06 2.17 7.86 2.21 7.66 2.24
20 15 7.96 1.64 7.77 1.67 7.58 1.71 7.39 1.74 7.20 1.77
24 17 8.40 1.63 8.20 1.66 8.00 1.70 7.80 1.73 7.60 1.76
¢
Model: ABYG22KRTA
AFR
m
3
/h
900
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 5.60 2.13 5.46 2.17 5.33 2.22 5.20 2.26 5.06 2.30
-10 -11 6.14 2.21 6.00 2.26 5.85 2.31 5.70 2.35 5.56 2.40
-5 -7 6.70 2.29 6.54 2.34 6.38 2.39 6.22 2.44 6.06 2.48
0 -2 7.26 2.36 7.08 2.41 6.91 2.46 6.74 2.51 6.56 2.56
5 3 7.81 2.44 7.63 2.49 7.44 2.54 7.25 2.59 7.07 2.64
7 6 8.40 2.44 8.20 2.49 8.00 2.54 7.80 2.59 7.60 2.64
10 8 8.05 2.30 7.86 2.35 7.67 2.40 7.48 2.45 7.29 2.49
15 10 7.49 2.08 7.31 2.12 7.13 2.17 6.95 2.21 6.77 2.24
20 15 7.04 1.77 6.87 1.80 6.70 1.84 6.53 1.88 6.37 1.91
24 17 7.32 1.75 7.14 1.79 6.97 1.82 6.80 1.86 6.62 1.89
¢
Model: ABYG24KRTA
AFR
m
3
/h
1,230
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 6.37 2.12 6.21 2.16 6.06 2.21 5.91 2.25 5.76 2.30
-10 -11 6.99 2.21 6.82 2.25 6.65 2.30 6.49 2.34 6.32 2.39
-5 -7 7.62 2.28 7.44 2.33 7.26 2.38 7.08 2.43 6.89 2.47
0 -2 8.25 2.35 8.06 2.40 7.86 2.45 7.66 2.50 7.47 2.55
5 3 8.89 2.43 8.67 2.48 8.46 2.53 8.25 2.58 8.04 2.63
7 6 9.56 2.43 9.33 2.48 9.10 2.53 8.87 2.58 8.65 2.63
10 8 9.16 2.29 8.94 2.34 8.72 2.39 8.51 2.44 8.29 2.48
15 10 8.52 2.07 8.31 2.11 8.11 2.16 7.91 2.20 7.70 2.23
20 15 8.00 1.76 7.81 1.80 7.62 1.83 7.43 1.87 7.24 1.90
24 17 8.32 1.74 8.13 1.78 7.93 1.81 7.73 1.85 7.53 1.88
- 16 -
4-2. Heating capacity 4. Capacity table
