1. Specifications
Type Inverter heat pump
Model name AOYG18KBTB AOYG22KBTB
Power supply 230 V ~ 50 Hz
Power supply intake Outdoor unit
Available voltage range 198—264 V
Starting current A 7.1 8.2
Fan
Airflow rate
Cooling
m
3
/h
2,160 2,240
Heating 1,830 1,960
Type × Q'ty Propeller × 1
Motor output W 49
Sound pressure level *1
Cooling
dB (A)
50 51
Heating 50 51
Sound power level
Cooling
dB (A)
62 63
Heating 62 63
Heat exchanger type
Dimensions
(H × W × D)
mm
Main1: 588 × 881 × 18.19
Main2: 588 × 851 × 18.19
Fin pitch 1.3
Rows × Stages 1 × 28
Pipe type Copper
Fin
Type (Material) Aluminum
Surface treatment PC fin
Compressor
Type DC Twin rotary
Motor output W 900 1,060
Refrigerant
Type (Global warming potential) R32 (675)
Factory charge g 1,020 1,250
Refrigerant oil
Type FW68S RmM68AF
Amount
cm
3
350 400
Enclosure
Material Steel sheet
Color
Beige
Approximate color of Munsell 10YR 7.5/1.0
Dimensions
(H × W × D)
Net
mm
632 × 799 × 290
Gross 692 × 940 × 375
Weight
Net
kg
36 38
Gross 40 42
Connection pipe
Size
Liquid
mm (in)
Ø6.35 (Ø1/4)
Gas Ø12.70 (Ø1/2)
Method Flare
Pre-charge length
m
20
Max. length 30
Max. height difference 20 25
Operation range
Cooling
°C
-15 to 46
Heating -15 to 24
Drain hose
Material PP
Tip diameter mm Ø13.0 (I. D.), Ø16.0 to Ø16.8 (O. D.)
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
– Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
– Pipe length: 5 m, Height difference: 0 m. (Between outdoor unit and indoor unit.)
• Protective function might work when using it outside the operation range.
• *1: Sound pressure level
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
• This data is based on EN 14511 standard.
- 62 -
1. Specifications
OUTDOOR UNIT AOYG18-45KBTB OUTDOOR UNIT AOYG18-45KBTB
