22 Evaporator Total Assy
21 Drain pan sub assy
Ref.
Description
Part number
Bracket pipe sub assy
9374517978
9374513017
Main panel sub assy
22
21
3-3. Models: ARXG22KMLA and ARXG24KMLA - (02-16) - 3. Indoor unit parts list
TECHNICAL DATA
AND PARTS LIST
TECHNICAL DATA
AND PARTS LIST
