– 8 –
Remote Control Unit Display
!7 Remote Control Unit Display
!8 Transmit Indicator
!9 Clock Display
@0 Operating Mode Display
@1 Timer Mode Display
@2 Fan Speed Display
@3 Temperature Set Display
@4 Timer Set Indicator
@5 Temperature Set Indicator
@6 Compact type SII, MII only
LOW
MED
QUIET
HIGH
AUTOAUTO
COOL
HEAT
DRY
FAN
OFF ON SLEEP
HM
°C
ON
OFF
CLOCK TIMER RESET
LOW HIGH
▲▲
17
18
19
20
21
22
23
24
25
26
