1.3.15 VERTICAL AIR DIRECTION ADJUSTMENT
Each time the button is pressed, the air direction range will change as follows :
– 15 –
During Cooling/Dry operation :
The thermostat temperature setting increases by 1°C as
soon as the ENERGY SAVE button is pressed, and then
increases by another 1°C after one hour has passed.
Afterwards, energy consumption is saved by continuing to
cool or dry at a thermostat temperature of 2°C more than
that set.
ENERGY SAVE setting
1 hour
ENERGY
SAVE ON
Set temperature
1˚C 2˚C
4
5
6
7
1
2
3
UNIVERSAL TYPE
7
6
5
4
3
2
1
WALL MOUNTED TYPE
1
2
3
4
5
6
COMPACT SII TYPE
Types of Airflow Direction Setting :
q,w,e,r : During Cooling/Dry Modes
t,y,u : During Heating mode
The Remote Control Unit's display does not change.
• Use the air direction adjustments within the ranges shown above.
• The vertical airflow direction is set automatically as shown, in accordance with the type of operation selected.
During Cooling/Dry mode : Horizontal flow q
During Heating mode : Downward flow u
• During AUTO mode operation, for the first minute after beginning operation, airflow will be horizontal q; the air direction can-
not be adjusted during this period.
