17
31 Evaporator Total Assy 9319327013
32 Joint Pipe Assy 9319322018
33 Joint Pipe Holder 9318901009
35
34
Filter Guide 9318887006
36 Evaporator Holder L 9318875003
Base 9318874006
37 Air Seal 9319295008
Ref. Description Part number
INDOOR UNIT
Evaporator
2012.12.25
31
