Fujitsu AS* G09LECB Service Manual

43
49
48
44
42
41
46
47
45
INDOOR UNIT
Control box
18
46
Terminal 990063801645
Earth Terminal 9318918007
41
Control Box
9318916003
42
Cover Shield A
9318882018
43 Box Shield Assy 9319344003
Main PCB 970871322944
49 Step Motor 9900384166
47 Room Thermistor Holder 9319068008
48 Gear Cover 9318902006
Ref. Description Part number
56
Display PCB 970882401757
-- Thermistor Assy 9900627003
Display Assy 9708823010
54 Grille Key Top 9319334004
55 Micro Switch 9900625009
51 Panel Gear 9319293004
Switch Case 9319332000
52
53
Gear Case 9318903003
50 Gear B 9319294001
2012.12.25
52
53
50
51
54
55
56
57
