En-3
Fig. 6 Remote Control Unit
K Signal Transmitter
L MASTER CONTROL button
M SLEEP button
N TIMER MODE button
O FAN CONTROL button
P START/STOP button
Q SET TEMP. button (
/ )
R SET button
S SWING button
T TIMER SET ( / ) button
U CLOCK ADJUST button
V TEST RUN button
● This button is used when installing the condi-
tioner, and should not be used under normal
conditions, as it will cause the air conditioner’s
thermostat function to operate incorrectly.
● If this button is pressed during normal opera-
tion, the unit will switch to test operation mode,
and the Indoor Unit’s OPERATION Indicator
Lamp and TIMER Indicator Lamp will begin
to fl ash simultaneously.
● To stop the test operation mode, press the
START/STOP button to stop the air condi-
tioner.
W RESET button
X Remote Control Unit Display (Fig. 7)
Y Transmit Indicator
Z Temperature SET Display
[ Fan Speed Display
\ Operating Mode Display
] SWING Display
` SLEEP Display
a Timer Mode Display
b Clock Display
NAME OF PARTS
Fig. 1 Indoor Unit
1 Operating Control Panel (Fig. 2)
2 MANUAL AUTO button
●
When kept on pressing the MANUAL AUTO
button for more than 10 seconds, the forced
cooling operation will start.
● The forced cooling operation is used at the
time of installation.
Only for authorized service personnel’s use.
● When the forced cooling operation starts by
any chance, press the START/STOP button
to stop the operation.
3 Indicator (Fig. 3)
4 Remote Control Signal Receiver
5 OPERATION Indicator Lamp (green)
6 TIMER Indicator Lamp (orange)
●
If the TIMER indicator lamp fl ashes when the
timer is operating, it indicates that a fault has
occurred with the timer setting (See Page 14
Auto Restart).
7 SUPER QUIET Indicator Lamp (yellow)
8 Intake Grille (Fig. 4)
9 Front Panel
0 Air Filter
A Air Flow Direction Louver
B Right-Left Louver
(behind Air Flow Direction Louver)
C Drain Hose
D Power Supply Plug
E Power Supply Cord
F Air Cleaning Filter
Fig. 5 Outdoor Unit
G Intake Port
H Outlet Port
I Pipe Unit
J Drain port (bottom)
● Refer to the folded out page on the cover.
