En-10
To select SWING Operation
Press the SWING button (Fig. 6 T).
The SWING Display (Fig. 7 b) will light.
Each time the SWING button is pressed, the swing operation will change in the following
order.
To stop SWING Operation
Press the SWING button and select STOP.
Airfl ow direction will return to the setting before swing was begun.
SWING OPERATION
Begin air conditioner operation before performing this procedure.
Up/down swing operation Left/right swing operation
Swing operation stops Up/down/left/right swing operation
About Swing Operation
● Up/down swing: Swing operation begins using the follow-
ing range according to the current airfl ow direction.
Airfl ow direction is 1–4 (for cooling, dry).
With the upper airfl ow-direction louver in the horizon-
tal position, the lower airfl ow-direction louver moves
(swings) to direct airfl ow to a wide area.
● Left/right swing: The airfl ow-direction louvers move (swing)
in the left/right airfl ow direction.
● Up/down/left/right swing: The airfl ow-direction louvers move
(swing) in both the up/down and left/right airfl ow directions.
●
The SWING operation may stop temporarily when the air
conditioner’s fan is not operating, or when operating at very
low speeds.
●
If the SET button(Vertical) is pressed during the up/down
swing operation, the up/down swing operation will stop and
if the SET button(Horizontal) is pressed during the left/right
swing operation, the left/right swing operation will stop.
CLEANING AND CARE
● Before cleaning the air conditioner, be sure to turn it off and disconnect the Power Supply Cord.
● Be sure the Intake Grille (Fig. 1 8) is installed securely.
● When removing and replacing the air fi lters, be sure not to touch the heat exchanger, as personal injury
may result.
CAUTION!
● To avoid excessive wear of the part and components or malfunctioning of the air conditioning, the user/consumer shall perform
preventive maintenance through an accredited technical assistance, periodically. To know the preventive maintenance periodicity,
the consumer shall check with the accredited installer or an accredited technical assistance.
● When used for extended periods, the unit may accumulate dirt inside, reducing its performance. We recommend that the unit be
inspected regularly, in addition to your own cleaning and care. For more information, consult authorized service personnel.
● It is recommended for the user/consumer to demand a copy of the Work Order every time there is a visit of a technical assistance
for verifi cation, maintenance, test or repair of the product.
● When cleaning the unit’s body, do not use water hotter than 40 °C, harsh abrasive cleansers, or volatile agents like benzene or
thinner.
● Do not expose the unit body to liquid insecticides or hairsprays.
● When shutting down the unit for one month or more, fi rst allow the fan mode to operate continuously for about one-half day to
allow internal parts to dry thoroughly.
9315345332-03_OM.indb 109315345332-03_OM.indb 10 2/25/2013 10:09:50 AM2/25/2013 10:09:50 AM
