En-16
OPERATING TIPS
Temperature and Humidity Range
Cooling Mode Dry Mode Heating Mode
Outdoor temperature About -10 to 46 °C About -10 to 46 °C About –15 to 24 °C
Indoor temperature About 18 to 32 °C About 18 to 32 °C
About 30 °C or less
● If the air conditioner is used under higher temperature conditioner than those listed, the built-in protection circuit may operate to
prevent internal circuit damage. Also, during Cooling and Dry modes, if the unit is used under conditions of lower temperature than
those listed above, the heat-exchanger may freeze, leading to water leakage and other damage.
● Do not use this unit for any purposes other than the Cooling, Dehumidifying, and air-circulation of rooms in ordinary dwellings.
● If the unit is used for long periods under high-humidity conditions, condensation may form on the surface of the indoor unit, and drip
onto the fl oor or other objects underneath. (About 80% or more).
● If the outdoor temperature is lower than the temperature scope in the list above, in order to keep safety operation of device, the
outdoor unit may stop operation for certain period of time.
SPECIFICATIONS
MODEL
INDOOR UNIT ASBA24LFC ASBA30LFC
OUTDOOR UNIT AOBR24LFL AOBR30LFT
TYPE HEAT & COOL SPLIT TYPE (REVERSE CYCLE)
POWER 220 V ~ 60 Hz
COOLING
CAPACITY [kW] 7.03 7.91
[BTU/h] 24,000 27,000
POWER INPUT [kW] 2.16 2.44
CURRENT (MAX.) [A] 9.9 (13.5) 11.2 (17.0)
ENERGY EFFICIENCY RATIO [kW/kW] 3.26 3.24
AIRFLOW INDOOR UNIT [m
3
/h] 1,100 1,100
OUTDOOR UNIT [m
3
/h] 2,470 3,600
HEATING
CAPACITY [kW] 7.91 9.08
[BTU/h] 27,000 31,000
POWER INPUT [kW] 2.31 2.77
CURRENT (MAX.) [A]
10.6 (18.5) 12.7 (19.0)
ENERGY EFFICIENCY RATIO [kW/kW] 3.42 3.28
AIRFLOW INDOOR UNIT [m
3
/h] 1,120 1,150
OUTDOOR UNIT [m
3
/h] 2,570 3,600
MAX. PRESSURE [MPa] 4.12 4.12
REFRIGERANT (R410A) [kg] 1.65 2.10
DIMENSIONS & WEIGHT (NET)
INDOOR UNIT
HEIGHT [mm] 320
WIDTH [mm] 998
DEPTH [mm] 228
WEIGHT [kg] 14
OUTDOOR UNIT
HEIGHT [mm] 578 830
WIDTH [mm] 790 900
DEPTH [mm] 315 330
WEIGHT [kg] 43 61
AUTO Restart
In Event of Power Interruption
● The air conditioner power has been interrupted by a power
failure. The air conditioner will then restart automatically in
its previous mode when the power is restored.
● Operated by setting before the power failure.
●
If a power failure occurs during TIMER operation, the timer will
be reset and the unit will begin (or stop) operation at the new
time setting. In the event that this kind of timer fault occurs the
TIMER Indicator Lamp will fl ash (see Page. 4).
● Use of other electrical appliances (electric shaver, etc.) or
nearby use of a wireless radio transmitter may cause the air
conditioner to malfunction. In this event, temporarily discon-
nect the Power Supply Plug, reconnect it, and then use the
Remote Controller to resume operation.
9315345318-03_OM.indb 169315345318-03_OM.indb 16 2/26/2013 11:12:57 AM2/26/2013 11:12:57 AM
