16
MODEL
INDOOR UNIT AST24PBA AST30PBA
OUTDOOR UNIT AOT24PMAL AOT30PMAL
TYPE HEAT&COOL MULTI SPLIT TYPE (REVERSE CYCLE)
POWER 240-(220) V~ 50 Hz 240-(220) V~ 50 Hz
COOLING
CAPACITY [W(A)] 7,100(1,400-8,000) 8,000(1,400-8,500)
POWER INPUT [W] 2,630(600-3,350) 3,300(600-3,950)
CURRENT [A] 11.0(2.8-14.0) 13.8(2.8-16.5)
ENERGY EFFICIENCY RATIO 2.70 2.42
HEATING
CAPACITY [W] 8,500(1,400-9,500) 9,500(1,400-10,200)
POWER INPUT [W] 2,740(500-3,350) 3,320(500-3,950)
CURRENT [A] 11.5(2.3-14.0) 13.9(2.3-16.5)
MAX. PRESSURE [MPa] 2.7
REFRIGERANT [R22] [g] 2,200
DIMENSIONS & WEIGHT (NET)
INDOOR UNIT
HEIGHT 320 mm
WIDTH 1,120 mm
DEPTH 220 mm
WEIGHT 16 kg
OUTDOOR UNIT
HEIGHT 900 mm
WIDTH 900 mm
DEPTH 350 mm
WEIGHT 80 kg
SPECIFICATIONS
