Fig. 6 Remote Control Unit
H SLEEP button
I MASTER CONTROL button
J SET TEMP./SET TIME buttons (
)
K Signal Transmitter
L TIMER button
M FAN CONTROL button
N START/STOP button
O AIR FLOW DIRECTION
VERTICAL SET button
P AIR FLOW DIRECTION
VERTICAL SWING button
Q AIR FLOW DIRECTION
HORIZONTAL SET button
R AIR FLOW DIRECTION
HORIZONTAL SWING button
Rear side (Fig. 7)
S TIME ADJUST button
T ACL button
(located inside battery compartment)
U TEST RUN button
● This button is used when installing the air
conditioner and should not be used under
normal conditions as it will cause the air
conditioner’s thermostat function to oper-
ate incorrectly.
● If this button is pressed during normal op-
eration, the unit will switch to test opera-
tion mode, and the indoor unit’s OPERA-
TION indicator lamp and TIMER indicator
lamp will begin to flash simultaneously.
● To stop the test operation mode, either
press the TEST RUN button once again, or
press the START/STOP button to stop the
air conditioner.
V Remote Control Unit Display (Fig. 8)
W Transmit Indicator
X Clock Display
Y Operating Mode Display
Z T imer Mode Display
[ Fan Speed Display
\ Temperature Set Display
] T imer Set Indicator
` Temperature Set Indicator
Fig. 1 Indoor Unit
1 Operating Control Panel (Fig. 2)
2 MANUAL AUTO button
3 Indicator Panel (Fig. 3)
4 Remote Control Signal Receiver
5 OPERATION Indicator Lamp (red)
6 TIMER Indicator Lamp (green)
7 SWING Indicator Lamp (orange)
(VERTICAL SWING)
8 SWING Indicator Lamp (orange)
(HORIZONTAL SWING)
●
If the TIMER indicator lamp flashes when
the timer is operating, it indicates that a
fault has occurred with the timer setting
(See page 15 Auto Restart).
9 Intake Grille (Fig. 4)
; UP/DOWN Air Direction Flaps
A Moving Diffuser
B RIGHT/LEFT Air Direction Louvers
(behind UP/DOWN Air Direction Flaps)
C Drain Hose
D Air Filter
Fig. 5 Outdoor Unit
E Intake Port
F Outlet Port
G Pipe Unit
