Fujitsu AST9LSACW User Manual

5
Fig. 1 Indoor Unit
1 Operating Control Panel (Fig. 2)
2 MANUAL AUTO button
3 Indicator (Fig. 3)
4 Remote Control Signal Receiver
5 OPERATION Indicator Lamp (red)
6 TIMER Indicator Lamp (green)
●
If the TIMER indicator lamp flashes when
the timer is operating, it indicates that a
fault has occurred with the timer setting
(See Page 15 Auto Restart).
7 SUPER QUIET Indicator Lamp (green)
8 COIL DRY Indicator Lamp (orange)
9 Intake Grille
0 Open Panel (Fig. 4)
A Air Filter
B Air Flow Direction Louver
C Right-Left Louver
(behind Air Flow Direction Louver)
D Drain Hose
E Power Supply Plug
F Power Supply Cord
G Air Cleaning Filter (optional)
Fig. 5 Outdoor Unit
H Intake Port
I Outlet Port
J Pipe Unit
K Drain port (bottom)
Fig. 6 Remote Control Unit
L SLEEP button
M MASTER CONTROL button
N SET TEMP. button (
/ )
O COIL DRY button
P Signal Transmitter
Q OFF TIMER button
R ON TIMER button
S SET TIMER button
T CANCEL TIMER button
U FAN CONTROL button
V START/STOP button
W AIR FLOW DIRECTION button
X SWING button
Y ACL button
Z TEST RUN button
● This button is used when installing the
conditioner, and should not be used un-
der normal conditions, as it will cause the
air conditioner’s thermostat function to op-
erate incorrectly.
● If this button is pressed during normal op-
eration, the unit will switch to test opera-
tion mode, and the Indoor Unit’s OPERA-
TION Indicator Lamp and TIMER Indicator
Lamp will begin to flash simultaneously.
● To stop the test operation mode, press the
START/STOP button to stop the air condi-
tioner.
[ Remote Control Unit Display (Fig. 7)
\ Transmit Indicator
] Operating Mode Display
` Timer Mode Display
OFF TIMER Mark:
ON TIMER Mark:
SLEEP TIMER Mark:
a Fan Speed Display
b Temperature and time Display
It displays the temperature setting. How-
ever, when making the Timer setting, it will
display the Timer time. (The temperature
setting will reappear after finishing the
timer setting)
c COIL DRY Display
d SWING Display
9312556052-En.pm6.5 2003.5.14, 9:17 AM5
