Fujitsu AST9RSHCW User Manual

3
Fig. 1 Indoor Unit
1 Operating Control Panel (Fig. 2)
2 POWER Switch
3 MANUAL AUTO button
4 Remote Control Signal Receiver
5 Indicator Lamps (Fig. 3)
6 OPERATION Indicator Lamp (red)
7 TIMER Indicator Lamp (green)
●
If the TIMER indicator lamp flashes when
the timer is operating, it indicates that a
fault has occurred with the timer setting
(See Page 13 Auto Restart).
8 SWING Indicator Lamp (orange)
9 Intake Grille (Fig. 4)
0 Air Filter
A Air Flow Direction Louver
B Right-Left Louver
(behind Air Flow Direction Louver)
C Power Diffuser
D Drain Hose
E Power Supply Plug
F Power Supply Cord
G Air Cleaning Filter (optional)
Fig. 5 Outdoor Unit
H Intake Port
I Outlet Port
J Pipe Unit
K Drain port (bottom)
Fig. 6 Remote Control Unit
L SLEEP button
M MASTER CONTROL button
N SET TEMP./SET TIME buttons (
)
O Signal Transmitter
P TIMER button
Q FAN CONTROL button
R START/STOP button
S AIR FLOW DIRECTION button
T SWING LOUVER button
Rear side (Fig. 7)
U TIME ADJUST button
V ACL button
(located inside battery compartment)
W TEST RUN button
● This button is used when installing the
conditioner, and should not be used un-
der normal conditions, as it will cause the
air conditioner’s thermostat function to op-
erate incorrectly.
● If this button is pressed during normal op-
eration, the unit will switch to test opera-
tion mode, and the Indoor Unit’s OPERA-
TION Indicator Lamp and TIMER Indicator
Lamp will begin to flash simultaneously.
● To stop the test operation mode, press the
START/STOP button to stop the air condi-
tioner.
X Remote Control Unit Display (Fig. 8)
Y Transmit Indicator
Z Clock Display
[ Operating Mode Display
\ Timer Mode Display
] Fan Speed Display
_ Temperature Set Display
a Timer Set Indicator
b Temperature Set Indicator
NAME OF PARTS
●
Refer to the fold-out page on the cover.
