4
Fig. 6 Remote Controller
J SLEEP button
K MASTER CONTROL button
L SET TEMP. button (
/ )
M COIL DRY button
N Signal Transmitter
O TIMER MODE button
P TIMER SET (
/ ) button
Q FAN CONTROL button
R START/STOP button
S SET button (Vertical)
T SET button (Horizontal)
U SWING button
V RESET button
W TEST RUN button
This button is used when installing the
conditioner, and should not be used un-
der normal conditions, as it will cause the
air conditioners thermostat function to op-
erate incorrectly.
If this button is pressed during normal op-
eration, the unit will switch to test opera-
tion mode, and the Indoor Unit’s OPERA-
TION Indicator Lamp and TIMER Indicator
Lamp will begin to flash simultaneously.
To stop the test operation mode, press the
START/STOP button to stop the air condi-
tioner.
X CLOCK ADJUST button
Y Remote Controller Display (Fig. 7)
Z Transmit Indicator
[ Clock Display
\ Operating Mode Display
] Timer Mode Display
` Fan Speed Display
a Temperature SET Display
b COIL DRY Display
c SLEEP Display
d SWING Display
NAME OF PARTS
Fig. 1 Indoor Unit
1 Operating Control Panel (Fig. 2)
2 MANUAL AUTO button
When kept on pressing the MANUAL
AUTO button for more than 10 seconds,
the forced cooling operation will start.
The forced cooling operation is used at the
time of installation.
Only for authorized service personnel's
use.
When the forced cooling operation starts
by any chance, press the START/STOP but-
ton to stop the operation.
3 Indicator (Fig. 3)
4 Remote Control Signal Receiver
5 OPERATION Indicator Lamp (red)
6 TIMER Indicator Lamp (green)
If the TIMER indicator lamp flashes when
the timer is operating, it indicates that a
fault has occurred with the timer setting
(See Page 15 Auto Restart).
7 COIL DRY Indicator Lamp (orange)
8 Intake Grille (Fig. 4)
9 Front Panel
0 Air Filter
A Air Flow Direction Louver
B Power Diffuser
C Right-Left Louver
(behind Air Flow Direction Louver)
D Drain Hose
E Air Cleaning Filter
Fig. 5 Outdoor Unit
F Intake Port
G Outlet Port
H Pipe Unit
I Drain port (bottom)
