- (01 - 11) -
WALL MOUNTED TYPE
ASTG18-24KMCA
WALL MOUNTED TYPE
ASTG18-24KMCA
FAN PERFORMANCE7.
AIR VELOCITY DISTRIBUTION7-1.
MODEL
: ASTG18KMCA
Conditions:
Fan speed : HIGH
Operation mode : FAN
2.0
1.0
0.5
2
1
0
1
2
Unit: m/s(m)
(m)
Top view
Vertical airow direction louver: Up
Horizontal airow direction louver: Center
0 1 2 3 4 5 6 7 8 9
1.0
1.0
2.0
0.5
0.5
2.0
3
2
1
0
1
2
3
Unit: m/s(m)
Top view
Vertical airow direction louver: Up
Horizontal airow direction louver: Right & Left
(m)
0 1 2 3 4 5 6 7 8 9
1.0
2.0
0.5
0.5
3
2
1
0
Unit: m/s(m)
Side view
Vertical airow direction louver: Up
Horizontal airow direction louver: Center
(m)
0 1 2 3 4 5 6 7 8 9
2.0
1.0
0.5
3
2
1
0
Unit: m/s(m)
Side view
Vertical airow direction louver: Down
Horizontal airow direction louver: Center
(m)
0 1 2 3 4 5 6 7 8 9
