En-6
6.1. Weekly timer
Setting details
1. Select Weekly timer in step 2 of "Timer setting procedure".
2. Press
()
to select the program number and the
day of the week.
Selected program number (1~4) and the day of the week will blink.
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
3. Press
.
4. Press
to choose the timer operation.
5. Press
.
* When you chose "Without a timer" in step 4, the setting display will
return to step 1.
6. Press
()
to set on time or o󰀨 time.
7. Press
.
* When you chose "O󰀨 timer" in step 4, the setting display will return
to step 1.
8. Press
()
to set the temperature.
Temperature setting range
Auto, Cooling,
or Dry mode:
18.0-30.0 °C
*Even if you set to 10, 16.0-17.5 °C, the air
conditioner will run at 18.0 °C.
Heating mode: 10 or 16.0-30.0 °C
9. Press
.
The setting display will return to step 1.
10. Press
to complete the setting.
Be close to the indoor unit.
NOTES: [
] indicator on the indoor unit will not turn on even if the
setting is complete.
If you want to return the previous step, press .
To check the schedule, use
()
to browse the Weekly
timer settings in step 1.
To  nish checking, press
.
To deactivate the Weekly timer, press
while is
shown on the remote controller display.
The indicator will disappear.
NOTES:
The operation modes will be the same as the mode at the last time
operation was stopped, so Cooling → Heating → Cooling → Heating
type of operations cannot be set automatically.
If you set the On timer and O󰀨 timer on the same time, the On timer
will work.
If two On timers are set on the same time, the air conditioner will run
in the order of the program number.
You cannot the Weekly timer and the other timers simultaneously.
If you use the On/O󰀨 timer, the Program timer, or the Sleep timer
while the Weekly timer is activated, the Weekly timer will be
deactivated.
In such a case, activate the Weekly timer after the other timer
nishes.
If the wired remote controller (optional) is connected, this function is
restricted.
Day of the week
Program number
(Without a timer)
(On timer) (O󰀨 timer)
Examples of Weekly timer
Example 1
7:00 9:00 11:00 17:00 23:00
Monday
to
Friday
Program
1
Program
2
Program
3
Program
4
On O 󰀨 On O 󰀨
26 °C 28 °C
Wake up Leave for
work
Come back
home
Go to
sleep
Saturday (No timer settings)
Sunday Program
1
Program
2
Program
3
Program
4
O 󰀨 O 󰀨 O 󰀨 O 󰀨
(On) (On) (On) (On)
Example 2: You can specify temperature settings using the On timer in
the Weekly timer.
7:00 9:00 17:00 23:00
Program 1 Program 2 Program 3 Program 4
On On On On
28 °C 26 °C 27 °C 28 °C
6.2. On timer or O󰀨 timer
1. Select On timer or O󰀨 timer in step 2 of "Timer setting
procedure".
2. Press
()
to set on time or o󰀨 time.
Pressing the button: The time will change by +5/-5 minutes.
Pressing down the button: The time will change by +10/-10 minutes.
To deactivate the On/O󰀨 timer, press
while is
shown on the remote controller display.
The indicator will disappear.
6.3. Program timer
1. Set On timer and O󰀨 timer. (Refer to "6.2. On timer or O󰀨
timer).
2. Select Program timer in step 2 of "Timer setting procedure".
The timer whose setting time is closer to the current time works  rst.
The order of the timer operation is displayed as follows:
Timer Indicator on the remote controller display
On→O󰀨 timer
O󰀨 →On timer
NOTES: You can set the Program timer only within a span of 24 hours.
6.4. Sleep timer
1. Select Sleep timer in step 2 of "Timer setting procedure".
2. Press
()
to set the time until the operation
stops.
Each time you press the button, the time changes as follows:
9H
00M
7H
00M
5H
00M
3H
00M
2H
00M
1H
00M
0H
30M
hours
(30 min.)
To deactivate the Sleep timer, press while is shown
on the remote controller display.
The indicator will disappear.
During the Sleep timer operation, the setting temperature changes as
the following  gure.
In Heating mode
Set
temperature
Set time
1 hour
Set time
1 hour
1.5 hour
30 min.
1 °C 2 °C 3 °C 4 °C
2 °C
1 °C
In Cooling or Dry mode
After the set time has elapsed, the air conditioner operation turns o󰀨 .
