8. COMPRESSOR CONTROL
1. OPEARTION FREQUENCY RANGE
The operation frequency of the compressor is different based on the operation mode as
shown in the table10.
Cooling Heating
Min Max Min Max Min Max
Dry
AOTG18KMTC
AOTG22KMTC
AOTG24KMTC
10rps 94rps 10rps 130rps 18rps 24rps
(Table10 : Compressor Operation Frequency Range)
2. OPEARTION FREQUENCY CONTROL AT START UP
The compressor frequency soon after the start-up is controlled as shown in the Fig.9.
(Fig.9 : Compressor Control at Start-up)
01-09
10rps 74rps 10rps 130rps 18rps 24rps
10rps 111rps 10rps 130rps 18rps 24rps
Time
Time Time Time
Time
(Frequency)
Frequency
Frequency
Frequency Frequency Frequency
Frequency
Frequency
Frequency
Frequency
Frequency
Time
Time Time Time
Time
60sec 140sec 170sec 200sec 350sec 410sec
(Time)
Frequency
Time
6
Frequency
Time
6
35rps 52rps 64rps 71rps 89rps 97rps
AOTG18/ 22/ 24KMTC
AOTG18/ 22/ 24KMTC
