En-4
Signal transmitter
Aim at the signal receiver of the indoor unit properly.
• Operating range is approximately 7 m.
• [
] will appear when the signal is transmitted.
• The indoor unit will emit a beep when it receive the signal
properly. If there is no beep, press the button again.
:
The setting must be done while the setting screen is displayed
for each function.
:
The button is controllable only when the air conditioner is
operating.
Do not press this button in normal use.
It starts the test run (for use by authorized service personnel only).
NOTE:
If the test run starts unintentionally, press
to quit the test
run.
Remote controller display
In this section, all the possible indicators are displayed for
description. In actual operation, the display is linked with the
button operation, and only shows the necessary indicators for
each setting.
For Basic operations ..................... Refer to page 5.
Starts or stops the air conditioner operation.
Changes the operation mode.
Adjusts the setting temperature./
Adjusts the value of the timer settings.
For Timer operations ..................... Refer to page 5.
Starts the timer setting.
Activates or deactivates the Sleep timer.
For Powerful operation ................. Refer to page 7.
Activates or deactivates the Powerful
operation.
For Energy saving operation ........ Refer to page 6.
Activates or deactivates the Economy
operation.
For Airfl ow settings ....................... Refer to page 5.
Controls the fan speed.
Sets the automatic Swing operation.
Controls the up/down airfl ow direction.
Controls the left/right airfl ow direction.
After replacing batteries ................ Refer to page 3.
Resets the settings of the remote controller.
Do not press this button in normal use.
If there seems to be a problem, check the error code. (Refer to page 10)
