6. OUTDOOR FAN CONTROL
( Table 7 : Outdoor fan speed )
*
The outdoor fan speed mentioned above depends on the compressor frequency.
(When the compressor frequency increases, the outdoor fan speed also changes to the higher
speed. When the compressor frequency decreases, the outdoor fan speed also changes to the
lower speed.)
*
After the defrost control is operated on the heating mode, the fan speed keeps at the higher speed
as Table 8 without relating to the compressor frequency.
01-06
( Table 8 : Outdoor fan speed after the defrost )
1. Outdoor Fan Motor
2. Fan Speed
AC Motor DC Motor
AOU9/ 12RLFW1
The Table 6 shows the type of the outdoor fan motor. The control method is different
between AC motor and DC motor.
( Table 6 : Type of Motor )
AOU9RLFW1 900rpm
Cooling Heating
AOU9RLFW1
AOU12RLFW1
Y
Z
Zone
860/ 780/ 760/ 470
900/ 760/ 720/ 680/ 470
950/ 850/ 750/ 680/ 550/ 480
Refer to Fig. 7
(rpm)
860/ 470/ 330
F
G
230/ 150
230/ 150
Y
Z
850/ 750/ 670/ 500
850/ 500/ 350
F
G
330/ 230
330/ 230
Dry
760/ 470
760/ 470
AOU12RLFW1 950rpm
( Fig. 7 : Outside air temperature zone selection )
69.8°F (21°C)
50°F (10°C)
Outside air
temperature
Outside air
temperature
Z zone
Y zone
F zone
G zone
53.6°F (12°C)
35.6°F ( 2°C)
66.2°F (19°C)
32°F ( 0°C)
