REPLACEMENT PARTS
03-23
Fig.10
CN1 (MAIN PCB)
WIRE WITH CONNECTOR
W200 RED (MAIN PCB)
WIRE WITH TERMINAL
W201 YELLOW(MAIN PCB)
WIRE WITH TERMINAL
CN39 (MAIN PCB)
WIRE WITH CONNECTOR
CN50 (MAIN PCB)
WIRE WITH CONNECTOR
Fig.9
REGULATIONS
MODEL : AOU24RML
As shown in Fig.9-10, pull out the wires.
