Fujitsu ASU18RMLQ User Manual

REPLACEMENT PARTS
03-28
PROCESS
MODEL : AOU24RML
Fig.1
Hook
120 10mm
210 10mm
INVERTER BOX A
Pull out the wire
through this opening.
HEATSINK
THERMISTOR
CN407(MAIN PCB)
WIRE WITH CONNECTOR
Fig.2
Fix the wires to INVERTER BOX A
.
(HEATSINK THERMISTOR, etc)
REGULATIONS
As shown in Fig.1,fix the wires to INVERTER BOX A.
+
-
+
-
