Fujitsu ASU24RLF Design & Technical Manual

 Indoor units: 14,000 Btu
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
14 13.58 10.38 0.60 15.34 10.37 0.61 16.18 11.44 0.62 17.32 12.00 0.62 18.51 12.28 0.63 19.08 13.65 0.63
23 13.01 10.13 0.68 14.70 10.12 0.69 15.50 11.16 0.70 16.60 11.71 0.71 17.74 11.98 0.72 18.29 13.32 0.72
32 12.79 10.03 0.75 14.45 10.01 0.77 15.23 11.05 0.77 16.31 11.59 0.78 17.43 11.86 0.79 17.97 13.18 0.79
41 12.67 9.98 0.77 14.32 9.96 0.79 15.10 10.99 0.79 16.16 11.53 0.80 17.28 11.80 0.81 17.81 13.11 0.81
50 12.79 10.03 0.78 14.45 10.01 0.80 15.23 11.05 0.80 16.31 11.59 0.81 17.43 11.86 0.82 17.97 13.18 0.83
59 12.79 10.03 0.86 14.45 10.02 0.88 15.23 11.05 0.88 16.31 11.59 0.89 17.43 11.86 0.90 17.97 13.18 0.91
67 13.49 10.39 0.89 15.25 10.38 0.90 16.07 11.45 0.91 17.21 12.01 0.92 18.40 12.29 0.93 18.97 13.66 0.94
77 12.94 10.10 0.91 14.63 10.09 0.92 15.42 11.13 0.93 16.51 11.67 0.94 17.65 11.94 0.95 18.19 13.28 0.96
87 12.15 9.69 1.01 13.73 9.68 1.03 14.47 10.68 1.03 15.49 11.20 1.05 16.56 11.46 1.06 17.07 12.74 1.06
95 13.25 10.24 1.40 14.98 10.23 1.43 15.79 11.28 1.44 16.91 11.84 1.46 18.07 12.11 1.47 18.63 13.46 1.48
104 12.57 9.93 1.56 14.20 9.92 1.58 14.97 10.94 1.60 16.03 11.48 1.62 17.14 11.74 1.63 17.67 13.05 1.64
115 11.38 9.52 1.69 12.86 9.51 1.72 13.56 10.49 1.74 14.52 11.00 1.76 15.52 11.26 1.78 16.00 12.51 1.79
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.2 19.4 21.7 22.8
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW
-10.0 3.98 3.04 0.60 4.50 3.04 0.61 4.74 3.35 0.62 5.08 3.52 0.62 5.43 3.60 0.63 5.59 4.00 0.63
-5.0 3.81 2.97 0.68 4.31 2.97 0.69 4.54 3.27 0.70 4.86 3.43 0.71 5.20 3.51 0.72 5.36 3.90 0.72
0.0 3.75 2.94 0.75 4.23 2.94 0.77 4.46 3.24 0.77 4.78 3.40 0.78 5.11 3.48 0.79 5.27 3.86 0.79
5.0 3.71 2.92 0.77 4.20 2.92 0.79 4.42 3.22 0.79 4.74 3.38 0.80 5.06 3.46 0.81 5.22 3.84 0.81
10.0 3.75 2.94 0.78 4.23 2.94 0.80 4.46 3.24 0.80 4.78 3.40 0.81 5.11 3.48 0.82 5.27 3.86 0.83
15.0 3.75 2.94 0.86 4.23 2.94 0.88 4.46 3.24 0.88 4.78 3.40 0.89 5.11 3.48 0.90 5.27 3.86 0.91
19.4 3.95 3.04 0.89 4.47 3.04 0.90 4.71 3.35 0.91 5.04 3.52 0.92 5.39 3.60 0.93 5.56 4.00 0.94
25.0 3.79 2.96 0.91 4.29 2.96 0.92 4.52 3.26 0.93 4.84 3.42 0.94 5.17 3.50 0.95 5.33 3.89 0.96
30.6 3.56 2.84 1.01 4.02 2.84 1.03 4.24 3.13 1.03 4.54 3.28 1.05 4.85 3.36 1.06 5.00 3.73 1.06
35.0 3.88 3.00 1.40 4.39 3.00 1.43 4.63 3.31 1.44 4.95 3.47 1.46 5.30 3.55 1.47 5.46 3.94 1.48
40.0 3.68 2.91 1.56 4.16 2.91 1.58 4.39 3.21 1.60 4.70 3.36 1.62 5.02 3.44 1.63 5.18 3.83 1.64
46.1 3.34 2.79 1.69 3.77 2.79 1.72 3.97 3.07 1.74 4.26 3.22 1.76 4.55 3.30 1.78 4.69 3.67 1.79
 Indoor units: 18,000 Btu
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
14 14.33 10.78 0.70 16.19 10.77 0.71 17.07 11.88 0.72 18.28 12.46 0.73 19.54 12.75 0.73 20.14 14.17 0.74
23 13.73 10.52 0.79 15.52 10.50 0.81 16.36 11.59 0.81 17.52 12.16 0.82 18.72 12.44 0.83 19.30 13.83 0.84
32 13.49 10.41 0.88 15.25 10.40 0.89 16.08 11.47 0.90 17.21 12.04 0.91 18.40 12.31 0.92 18.97 13.69 0.92
41 13.37 10.36 0.90 15.11 10.34 0.91 15.93 11.41 0.92 17.06 11.97 0.93 18.24 12.25 0.94 18.8 13.62 0.95
50 13.49 10.41 0.91 15.25 10.40 0.93 16.08 11.47 0.93 17.21 12.04 0.94 18.40 12.31 0.96 18.97 13.69 0.96
59 13.96 10.62 1.07 15.77 10.60 1.09 16.63 11.70 1.10 17.80 12.27 1.12 19.03 12.56 1.13 19.62 13.96 1.13
67 15.33 11.26 1.21 17.33 11.24 1.23 18.27 12.40 1.24 19.56 13.01 1.25 20.91 13.32 1.27 21.55 14.80 1.28
77 14.71 10.94 1.24 16.62 10.93 1.26 17.52 12.06 1.27 18.76 12.65 1.28 20.05 12.94 1.30 20.67 14.39 1.30
87 13.80 10.50 1.37 15.60 10.49 1.40 16.44 11.57 1.41 17.60 12.14 1.42 18.82 12.42 1.44 19.40 13.81 1.45
95 15.21 11.16 1.95 17.18 11.14 1.98 18.12 12.29 2.00 19.40 12.90 2.02 20.73 13.20 2.04 21.37 14.67 2.06
104 14.42 10.82 2.16 16.30 10.81 2.20 17.18 11.92 2.22 18.39 12.51 2.24 19.66 12.80 2.27 20.27 14.22 2.28
115 11.48 9.75 1.87 12.97 9.74 1.90 13.67 10.74 1.92 14.64 11.27 1.94 15.65 11.53 1.96 16.13 12.81 1.97
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.2 19.4 21.7 22.8
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW
-10.0 4.20 3.16 0.70 4.75 3.16 0.71 5.00 3.48 0.72 5.36 3.65 0.73 5.73 3.74 0.73 5.9 4.15 0.74
-5.0 4.02 3.08 0.79 4.55 3.08 0.81 4.79 3.40 0.81 5.13 3.56 0.82 5.49 3.65 0.83 5.66 4.05 0.84
0.0 3.95 3.05 0.88 4.47 3.05 0.89 4.71 3.36 0.90 5.04 3.53 0.91 5.39 3.61 0.92 5.56 4.01 0.92
5.0 3.92 3.04 0.90 4.43 3.03 0.91 4.67 3.34 0.92 5.00 3.51 0.93 5.34 3.59 0.94 5.51 3.99 0.95
10.0 3.95 3.05 0.91 4.47 3.05 0.93 4.71 3.36 0.93 5.04 3.53 0.94 5.39 3.61 0.96 5.56 4.01 0.96
15.0 4.09 3.11 1.07 4.62 3.11 1.09 4.87 3.43 1.10 5.22 3.60 1.12 5.58 3.68 1.13 5.75 4.09 1.13
19.4 4.49 3.30 1.21 5.08 3.30 1.23 5.35 3.64 1.24 5.73 3.81 1.25 6.13 3.90 1.27 6.32 4.34 1.28
25.0 4.31 3.21 1.24 4.87 3.20 1.26 5.13 3.53 1.27 5.50 3.71 1.28 5.88 3.79 1.3 6.06 4.22 1.30
30.6 4.04 3.08 1.37 4.57 3.07 1.40 4.82 3.39 1.41 5.16 3.56 1.42 5.51 3.64 1.44 5.69 4.05 1.45
35.0 4.46 3.27 1.95 5.04 3.27 1.98 5.31 3.60 2.00 5.68 3.78 2.02 6.08 3.87 2.04 6.26 4.30 2.06
40.0 4.23 3.17 2.16 4.78 3.17 2.20 5.03 3.49 2.22 5.39 3.67 2.24 5.76 3.75 2.27 5.94 4.17 2.28
46.1 3.36 2.86 1.87 3.80 2.85 1.90 4.01 3.15 1.92 4.29 3.30 1.94 4.59 3.38 1.96 4.73 3.76 1.97
- 217 -
6-2. Cooling capacity 6. Capacity table
OUTDOOR UNIT AOU24RLXFZ OUTDOOR UNIT AOU24RLXFZ
