Models: ASU7RLF, ASU9RLF, and ASU12RLF
Unit: in (mm)
8-1/16 (205) : Installed state
*1: Vertical flap is downward
8 (203)
5-1/2 (140) *1
6/16 (10) *1
5-11/16 (145) *1
31-1/8 (790)
11 (280)
3-11/16 (94)
2-1/16 (52)
3-1/16 (78)
ø2-9/16 (65)
for pipe inlet
ø2-9/16 (65)
for pipe inlet
Outline of unit
12-11/16 (323)
13-7/8 (353): Gas pipe
16-5/16 (415): Liquid pipe
12-7/8 (327)
9-5/16 (237)
17-11/16 (450)
8-1/4 (209)
2-7/16 (62)
11/16 (18)
1-7/8 (47)
1-7/8 (47)
7-1/4 (184)
8-7/16 (215)
11/16 (18)
3-1/4 (82)
- 23 -
3-3. Wall mounted type 3. Dimensions
MULTI TYPE 2, 3, 4 ROOMS TYPE MULTI TYPE 2, 3, 4 ROOMS TYPE
