Fujitsu ASU24RLF - Page 36


Installation space
3 (63) or more
4 (80) or more
3 (53) or more
3 (52) or more
4 (80) or more
Outline of unit
5 (120) or more
60 (1,500) or more
71 (1,800) or more
Unit: in (mm)
- 28 -
3-3. Wall mounted type 3. Dimensions
MULTI TYPE 2, 3, 4 ROOMS TYPE MULTI TYPE 2, 3, 4 ROOMS TYPE
