Outdoor unit: AOU45RLXFZ
No. Unit 1 Unit 2 Unit 3 Unit 4 Unit 5 Total
101 7 7 7 9 9 39
102 7 7 7 9 12 42
103 7 7 7 9 15 45
104 7 7 7 9 18 48
105 7 7 7 9 24 54
106 7 7 7 12 12 45
107 7 7 7 12 15 48
108 7 7 7 12 18 51
109 7 7 7 15 15 51
110 7 7 7 15 18 54
111 7 7 9 9 9 41
112 7 7 9 9 12 44
113 7 7 9 9 15 47
114 7 7 9 9 18 50
115 7 7 9 12 12 47
116 7 7 9 12 15 50
117 7 7 9 12 18 53
118 7 7 9 15 15 53
119 7 7 12 12 12 50
120 7 7 12 12 15 53
121 7 9 9 9 9 43
122 7 9 9 9 12 46
123 7 9 9 9 15 49
124 7 9 9 9 18 52
125 7 9 9 12 12 49
126 7 9 9 12 15 52
127 7 9 12 12 12 52
128 9 9 9 9 9 45
129 9 9 9 9 12 48
130 9 9 9 9 15 51
131 9 9 9 9 18 54
132 9 9 9 12 12 51
133 9 9 9 12 15 54
134 9 9 12 12 12 54
7: 7,000Btu/h, 9: 9,000Btu/h, 12: 12,000Btu/h, 15: 14,000Btu/h, 18: 18,000Btu/h,
24: 24,000Btu/h
- 5 -
1-1. Indoor unit connection patterns 1. Model lineup
MULTI-SPLIT TYPE 5-unit type MULTI-SPLIT TYPE 5-unit type
