Page #8 background image
5V 5V
5V
+
C202
47/
10V
C201
0.1
<F>
R201
47
<1/4W>
CN201
07 JB20 / PAP
1061 L=230
I C201
GP1UM261RKVF
D201 SLR-325MC GREEN
D202 SLR-325DC ORANGE
D203 SLR-325YC YELLOW
D204 SLR-325YC YELLOW
1
2
3
4
5
6
7
2
1
3
VCC
OUT
GND
INDOOR UNIT
INDICATOR PCB ASSEMBLY
K05EA-0800HSE-D0
2009.01.15 7
