PARTS
2
3
6
1
11
7
12
13
4
4
8
9
10
5
INDOOR UNIT
Front panel assy
2009.02.17 11
4 Air Filter
9315235015
1
Front Panel 9316060043
Front Panel Assy 9316151093
5
Receiver Window
9315138019
3
6
Shaft Cover
9316063013
2
Open Panel 9315164070
Rack L Assy 9315565013
10 Wire Cover 9315181022
-- Air Clean Filter Assy 9316474017
11 Screw Cap 9309002050
8 Rack R Assy 9315564016
9
Shaft
9315177018
7
Remote Control 931747505112
13
Remote Control Holder
9305642045
Ref. Description Part number
