Page #13 background imageLoading...
Page #13 background image
28
26
27
25
23
22
21
24
29
2009.03.02
12
21 Evaporator Assy 9316117013
22 Joint Pipe J Assy 9316131019
-- Separate Pipe 9316118010
29
Water Seal B
9316113022
23
Filter Guide
9316122017
25
24
Evaporator Total Assy
28 9316115019
Evaporator Holder R Assy
9315887016
26
Evaporator Holder L Assy
9315199010
27
Connection Pipe Assy
9316116016
Rear Bracket
9315253019
Ref. Description Part number
INDOOR UNIT
Evaporator
