Fujitsu ASU9RLS Service Manual

31
46
45
43
44
49
47
42
41
40
38
50
48
51
35
34
36
32
33
37
39
INDOOR UNIT
Casing assy
2009.02.17 13
34 Drain Hose 9314147029
35
Casing Cover B
9315182029
36 Casing Cover R 9315359025
37
R and L Louver
9315185020
44 Fan Guard 9317693011
45
Bearing C
9315024022
46
Crossflow Fan Assy
9306628017
47
Diffuser Spring
9315172013
48
Louver U
9315452016
50 Diffuser Z 9315174017
49 Diffuser U 9315173010
51 Bracket Panel 9315200013
31 Casing Assy 9316232020
32 Bracket Drain 9314161025
33 Drain Cap 9316177017
38 Bush B 9312156016
39 Pillar A 9315176011
40
Casing Cover F
9317682015
41 Joint B 9315175014
42
Spacer C
9315281012
43 Spacer D 9315282019
Ref. Description Part number
