Fujitsu ASU9RLS Service Manual

72
90
68
71
82
66
81
83
86
65
85
77
74
79
78
75
80
88
76
89
84
87
70
67
64
63
62
69
73
61
INDOOR UNIT
Control box
2009.02.18 14
67 9316537002
66
Rack Gear Assy
9900384012
69
Step Motor
9317683012
64
Controller PCB Assy (09)
9317684019
65
Controller PCB Assy (12)
9317685016
70
Earth Terminal
9302271002
68 Terminal 9900447014
61
Control Box
9708065076
61
Code Clamp
9708065083
62
Control Cover
Control Cover B
Control Cover C
9315168023
63 9315169020
78 Conduit Holder 9313951016
77 Bush A 9303529010
75 Motor Case 9315170033
76 Motor Case Cover 9315171023
90 Room Thermistor Holder 9317688017
79 Step Motor 9900384029
71 Terminal Cover A 9317686013
72 Terminal Cover B 9317687010
73 Motor Clamper 9315012012
74 Fan Motor 9602783021
84 Step Motor 9900139063
83 Louver Gear A 9315196019
81 Step Motor 9900384036
82 Spring 9315800015
88 Display PCB Assy 9707205039
87 Joint A 9315005014
85 Link A 9315008015
86 Link Holder 9315007018
89 Display Case 9315178015
80 Gear A 9309994003
Ref. Description Part number
