Fujitsu ASU9RLS2 - Indoor Unit Installation Place Requirements

- (01 - 07) -
WALL MOUNTED TYPE ASU9-15RLS2 WALL MOUNTED TYPE ASU9-15RLS2
INSTALLATION PLACE

Unit : in. (mm)
1-31/32 (50) or more
59-1/16 (1500) or more
9-23/32 (247)
2-5/32
(55)
5ft. 10-7/8 (1800) or more
13-9/32 (337)
6-5/16 (160) or more
1-31/32 (50) or more
6-5/16 (160) or more
3-15/16 (100) or more 4-23/32 (120) or more
Outline of Unit
