WALL MOUNTED TYPE ASU9-15RLS2 WALL MOUNTED TYPE ASU9-15RLS2
HEATING CAPACITY6-2.
MODEL

: ASU9RLS2
AFR : Air Flow Rate (CFM)
TC : Total Capacity (kBtu/h)
IP : Input Power (kW)
AFR : Air Flow Rate (m
3
/min)
TC : Total Capacity (kW)
IP : Input Power (kW)
MODEL

: ASU12RLS2
AFR : Air Flow Rate (CFM)
TC : Total Capacity (kBtu/h)
IP : Input Power (kW)
AFR : Air Flow Rate (m
3
/min)
TC : Total Capacity (kW)
IP : Input Power (kW)
AFR 500
Indoor temperature
°FDB 60 65 70 75
Outdoor temperature
°FDB °FWB TC IP TC IP TC IP TC IP
-5 -7 14.7 1.97 14.3 2.01 14.0 2.05 13.3 2.13
5 3 16.1 1.98 15.7 2.02 15.4 2.06 14.6 2.15
14 12 16.8 1.91 16.4 1.95 16.0 1.99 15.2 2.07
23 19 18.3 1.84 17.9 1.88 17.5 1.92 16.6 2.00
32 28 18.8 1.78 18.4 1.82 17.9 1.85 17.0 1.93
41 37 21.3 1.85 20.8 1.89 20.3 1.93 19.3 2.00
47 43 23.1 1.91 22.6 1.95 22.0 1.99 20.9 2.07
50 47 25.5 1.94 24.9 1.98 24.3 2.02 23.1 2.10
59 50 26.5 1.95 25.8 1.99 25.2 2.03 23.9 2.11
AFR 14.2
Indoor temperature
°CDB 15.6 18.3 21.1 23.9
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP
-20.6 -21.7 4.31 1.97 4.20 2.01 4.10 2.05 3.90 2.13
-15.0 -16.1 4.73 1.98 4.61 2.02 4.50 2.06 4.28 2.15
-10.0 -11.1 4.91 1.91 4.80 1.95 4.68 1.99 4.45 2.07
-5.0 -7.2 5.38 1.84 5.25 1.88 5.12 1.92 4.86 2.00
0.0 -2.2 5.52 1.78 5.39 1.82 5.26 1.85 5.00 1.93
5.0 2.8 6.25 1.85 6.10 1.89 5.95 1.93 5.65 2.00
8.3 6.1 6.77 1.91 6.61 1.95 6.45 1.99 6.13 2.07
10.0 8.3 7.48 1.94 7.30 1.98 7.13 2.02 6.77 2.10
15.0 10.0 7.75 1.95 7.57 1.99 7.38 2.03 7.02 2.11
AFR 14.2
Indoor temperature
°CDB 15.6 18.3 21.1 23.9
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP
-20.6 -21.7 4.63 2.02 4.52 2.06 4.41 2.10 4.19 2.18
-15.0 -16.1 5.16 2.02 5.03 2.06 4.91 2.10 4.66 2.19
-10.0 -11.1 5.36 1.94 5.23 1.98 5.10 2.02 4.85 2.10
-5.0 -7.2 5.86 1.87 5.72 1.91 5.58 1.95 5.30 2.02
0.0 -2.2 6.03 1.80 5.88 1.84 5.74 1.88 5.45 1.95
5.0 2.8 6.58 1.86 6.43 1.90 6.27 1.94 5.96 2.02
8.3 6.1 6.80 1.92 6.64 1.96 6.48 2.00 6.15 2.08
10.0 8.3 7.52 1.94 7.34 1.98 7.16 2.02 6.80 2.10
15.0 10.0 7.79 1.95 7.60 1.99 7.42 2.03 7.05 2.11
AFR 500
Indoor temperature
°FDB 60 65 70 75
Outdoor temperature
°FDB °FWB TC IP TC IP TC IP TC IP
-5 -7 15.8 2.02 15.4 2.06 15.0 2.10 14.3 2.18
5 3 17.6 2.02 17.2 2.06 16.8 2.10 15.9 2.19
14 12 18.3 1.94 17.8 1.98 17.4 2.02 16.5 2.10
23 19 20.0 1.87 19.5 1.91 19.0 1.95 18.1 2.02
32 28 20.6 1.80 20.1 1.84 19.6 1.88 18.6 1.95
41 37 22.5 1.86 21.9 1.90 21.4 1.94 20.3 2.02
47 43 23.2 1.92 22.7 1.96 22.1 2.00 21.0 2.08
50 47 25.6 1.94 25.0 1.98 24.4 2.02 23.2 2.10
59 50 26.6 1.95 25.9 1.99 25.3 2.03 24.0 2.11
