WALL MOUNTED TYPE ASU9-15RLS2 WALL MOUNTED TYPE ASU9-15RLS2
MODEL

: ASU15RLS2
AFR : Air Flow Rate (CFM)
TC : Total Capacity (kBtu/h)
SHC : Sensible Heat Capacity (kBtu/h)
IP : Input Power (kW)
AFR : Air Flow Rate (m
3
/min)
TC : Total Capacity (kW)
SHC : Sensible Heat Capacity (kW)
IP : Input Power (kW)
AFR 529
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
67 13.5 9.6 0.84 15.0 9.6 0.86 16.6 10.5 0.87 17.1 11.4 0.87 18.1 11.3 0.88 19.1 12.1 0.89
77 12.9 9.1 0.95 14.3 9.2 0.96 15.8 10.0 0.98 16.3 10.8 0.98 17.2 10.8 0.99 18.2 11.5 1.00
87 12.2 8.7 1.06 13.6 8.7 1.07 15.0 9.5 1.09 15.4 10.3 1.10 16.4 10.2 1.11 17.3 10.9 1.12
95 11.5 8.1 1.17 12.8 8.2 1.19 14.1 8.9 1.20 14.5 9.6 1.21 15.4 9.6 1.22 16.2 10.2 1.23
104 10.1 7.2 1.15 11.2 7.2 1.17 12.4 7.9 1.19 12.7 8.5 1.19 13.5 8.4 1.20 14.3 9.0 1.22
115 9.2 6.5 1.13 10.2 6.6 1.15 11.3 7.2 1.17 11.6 7.7 1.17 12.3 7.7 1.19 13.0 8.2 1.20
AFR 15.0
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.7 19.4 21.7 22.8
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
19.4 3.95 2.81 0.84 4.40 2.83 0.86 4.85 3.08 0.87 5.00 3.33 0.87 5.30 3.32 0.88 5.60 3.53 0.89
25.0 3.77 2.68 0.95 4.20 2.69 0.96 4.63 2.94 0.98 4.77 3.17 0.98 5.05 3.16 0.99 5.34 3.37 1.00
30.6 3.57 2.54 1.06 3.98 2.56 1.07 4.39 2.79 1.09 4.52 3.01 1.10 4.79 3.00 1.11 5.07 3.19 1.12
35.0 3.36 2.39 1.17 3.74 2.40 1.19 4.12 2.62 1.20 4.25 2.83 1.21 4.50 2.82 1.22 4.76 3.00 1.23
40.0 2.95 2.10 1.15 3.29 2.11 1.17 3.62 2.30 1.19 3.73 2.48 1.19 3.96 2.48 1.20 4.18 2.64 1.22
46.0 2.69 1.91 1.13 2.99 1.92 1.15 3.30 2.10 1.17 3.40 2.26 1.17 3.61 2.25 1.19 3.81 2.40 1.20
